Technical data:

• DN 50-2000
• PN 10, 16, 25 , 40 , 64
• End Configuration: ISO,EN, ANSI , ASME
• Working Temperature: 50°C , 90°C - For hot water
• Lining Hard rubber, soft rubber, PTFE, PFA, ETFE
• Protection class IP 67 or IP 68
• Fluid temperature Up to 180 °C (356 °F)
• Ex approvals ATEX, IEC Zone 1 and Zone 2,
• FM, CSA Div 1 and Div 2, NEPSI Zone 1 and Zone 2, GOST
• Inputs/Outputs: Analog output (4...20 mA), pulse output, contact input/output
• Communication HART protocol (standard)
• Verification tool “ScanMaster” software
